Overview:

Are you looking for a scalable, compute-dense solution for high-performance workloads such as VDI, EDA, or CAD?

The HPE ProLiant DL360 Gen11 server is a rack-optimized 1U dense solution that delivers exceptional compute performance, upgraded high-speed data transfer rate, and memory depth with 2P compute capability. Powered by 4th Gen Intel® Xeon® Scalable processors with up to 60 cores, increased memory bandwidth, up to 8 TB of memory, and high-speed PCIe Gen5 I/O, the HPE ProLiant DL360 Gen11 server is a perfect rack-optimized, 1U 2P, dense solution for general-purpose virtualization workloads that require increased compute density with built-in security and flexibility.

The silicon root of trust anchors the server firmware to an HPE-exclusive ASIC, creating an immutable fingerprint for the Secure Intel Processor that must be matched exactly before the server will boot. The HPE ProLiant DL360 Gen11 server is an excellent choice for EDA, CAD, and VDI.

What's New

  • Powered by 4th Gen Intel® Xeon® Scalable processors with next-generation technology that supports up to 60 cores at 350W, and 16 DIMMs for up to 8 TB of high bandwidth DDR5 memory up to 4800 MHz.
  • 16 DIMMs per processor for up to 8 TB total DDR5 memory per server with increased performance, High Bandwidth Memory (HBM) support, and lower power requirements.
  • Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2 x16 PCIe Gen5 and 2 OCP slots.
  • Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
  • Supports up to 2 single wide (SW) GPUs1 to accelerate graphic intense workloads.
  • Supports Smart Cooling Modules for highest thermal design points (TDPs).

Features:

Intuitive Cloud Operating Experience: Simple, Self-service, and Automated

HPE ProLiant DL360 Gen11 servers are engineered for your hybrid world. ProLiant DL360 Gen11 servers are powered by 4th Generation Intel® Xeon® processors and simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.

Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console.

Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management to reduce and shorten maintenance windows.

Self-service automated experiences are engineered and built into all HPE ProLiant Gen11 servers, whether purchased as physical servers or consumed as-a-service using HPE GreenLake as your compute and storage demands grow.

Simplify and secure server management from edge to cloud with HPE GreenLake for Compute Ops Management. HPE GreenLake for Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally.

Trusted Security by Design: Uncompromising, Fundamental, and Protected

The HPE ProLiant DL360 Gen11 server is tied into the Silicon Root of Trust and the Intel® Xeon® Scalable Processor, a dedicated security processor embedded in the system to manage secure boot, memory encryption, and secure virtualization.

HPE ProLiant Gen11 servers use the Silicon Root of Trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel® Xeon® processor that must be matched exactly before the server will boot. This ensures malicious code is contained and healthy servers are protected.

HPE ProLiant Gen11 servers continuously protect healthy servers by a) providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies malicious code, and b) securing servers at the edge with IDevID certificates installed by default.

HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, and data connections, providing a fast path to bring a server back online and into normal operations.

Embedded in Hewlett Packard Enterprise servers, HPE Integrated Lights-Out 6 (iLO 6) is an exclusive core intelligence that monitors server status, providing the means for reporting, ongoing management, service alerting, and local or remote management to quickly identify and resolve issues.

Optimized Performance for your Workloads: Accelerated, Open, and Efficient

The HPE ProLiant DL360 Gen11 server is an excellent choice for EDA, CAD, and general-purpose virtualization workloads (including large-scale VDI), and Platforms (VCF & Containers) that require increased compute density with built-in security and flexibility.

Harness major computer performance. The HPE ProLiant DL360 Gen11 server is powered by the 4th Generation Intel® Xeon® Scalable Processors with next-generation technology that supports up to 60 cores, 350W, and up to 8 TB of memory.

The HPE ProLiant DL360 Gen11 server provides advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2 x16 PCIe Gen5 and 2 OCP slots to improve I/O throughput and reduce latency.

The server provides 16 DIMMs per processor for up to 8 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.

The HPE ProLiant DL360 Gen11 server provides real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.


Note: GPU support available Q2 2023. Subject to change.

Specifications:


HPE ProLiant DL360 Gen11 Server Specifications
Processor Type Intel®
Processor family 4th Generation Intel® Xeon® Scalable Processors
Processor core available 8 to 60 core, depending on processor.
Processor cache 12 - 60 MB L3, depending on processor
Maximum memory 4.0 TB per socket, when populated with 256 GB DDR5
Memory slots 16 DIMM slots per socket
Memory type HPE DDR5 SmartMemory
Memory protection features HPE Fast Fault Tolerant Memory
Advanced ECC Memory
Online Spare Memory
Mirrored Memory
Drive supported Up to 4 LFF SAS/SATA HDDs or SSDs.
Up to 8+2 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.3 SDDs, depending on model.
Up to 2x RAID 1 NVMe M.2 Boot device (Internal modular or external accessible from rear wall).
Infrastructure management Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download).
Optional - HPE iLO Advanced, and HPE OneView Advanced.
System fan features Standard Fan Kit (Q'ty 5), Performance Fan Kit (Q'ty 7), Close Loop Liquid Cooling Heatsink & Fan kit, Direct Liquid Cooling & Fan Kit, depending on model.
Power supply type HPE 800W Flex Slot Platinum Hot Plug Power Supply, HPE 1000W Flex Slot Titanium Power Supply, HPE 1600W Flex slot Platinum Hot Plug Power Supply, HPE 1600W DC Power supply, HPE 1600W Flex Slot -48VDC Hot Plug Power Supply, HPE 1800W-2200W Flex Slot Titanium Hot Plug Power Supply, depending on model.
Expansion slots Maximum 3 PCIe Gen5 slots and maximum 2 OCP 3.0 PCIe5 slots, for detail descriptions please see QuickSpecs.
Network controller Wide range of speeds, cabling, chipsets and form factors (PCIe stand-up adapter and OCP3.0). Please see QuickSpecs for network card choices.
Storage controller Included - Embedded SATA controller (AHCI or Intel SATA software RAID controller)
Optional - HPE Smart Array Gen11 Storage Controller in Variety of protocols -including NVMe-, port count, array utilities, and form factors (PCIe stand-up adapter and OCP3.0). Please see QuickSpecs for storage controllers selection.
Warranty 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, please Contact Us.
Processor number 1 or 2
Processor speed 3.7 GHz, maximum depending on processor.
Optical drive type Optional - HPE 9.5mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive.
Security UEFI Secure Boot and Secure Start support.
Intel® Software Guard Extensions (SGX) support.
Immutable Silicon Root of Trust.
Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits.
DIMM capacity 16 GB to 256 GB

Hardware Specs:

HPE ProLiant DL360 Gen11 server

8 SFF Front View
8 SFF Front View – 8 SFF + optional Universal Media Bay, optical drive, Display Port, USB2.0 and SAS drives shown

1 Drive support label
2 Quick removal access panel
3 Serial number/iLO information pull tab (optional - shown)
4 Universal Media Bay (optional):
  • Option: Optical drive bay + Display port & USB 2.0 port kit (shown)
  • Option: 2 SFF 24G x4 Tri-Mode SAS/SATA/U.3 NVMe cage
5 Display Port (optional – shown)
6 Optical drive (optional – shown)
7 USB2.0 port (optional)
8 iLO Service port
9 Power On/Standby button and system power LED
10 Health LED
11 NIC status LED
12 Unit ID button/LED
13 USB 3.2 Gen1 port
14 Drive bays; optional backplanes:
  • Option: 8 SFF x1 24G Tri-Mode SAS/SATA/U.3 NVMe
  • Option: 8 SFF x4 24G Tri-Mode SAS/SATA/U.3 NVMe

Notes: Optional- Systems Insight Display (SID) module is available for 8SFF CTO Server, and will be installed at the left-hand side of iLO Service port and USB 3.2 Gen1 port.


4 LFF Front View
4 LFF Front View – 4 LFF + optional Optical drive, Display Port, USB2.0 and SAS drives shown

1 Drive support label
2 Optical drive (optional – shown)
3 Serial number/iLO information pull tab
4 Quick removal access panel
5 Option: Display port & USB 2.0 port bundle Kit (blank shown)
6 USB 3.2 Gen1 port
7 iLO Service Port
8 Power On/Standby button and system power LED
9 Health LED
10 NIC status LED
11 Unit ID button/LED
12 SAS/SATA drive bays

Notes: Systems Insight Display (SID) module is not available in 4LFF CTO Server.


Internal View
Internal View - Standard for all DL360 Gen11

1 Liquid Cooling Module connector
2 x8 SlimSAS ports (1A to 4A, 1B to 4B)
3 DDR5 DIMM Slots (fully populated 32 DIMMs shown)
4 Socket 2 MCIO ports (1 & 2)
5 Backplane Power connector
6 Internal USB port (top USB 3.2 Gen1 and bottom USB 2.0)
7 Redudant Power Supply (1 & 2 as shown)
8 Secondary (CPU 2) Riser PCIe 5.0
  • Option: Low Profile x16
  • Option: Full height x16 (lose Slot 2 on Primary Riser)
9 SID connector (optional feature, 8SFF only)
10 Energy Pack connector
11 OCP Slot port
12 HPE NS204i-u NVMe Hot Plug Boot Optimized Storage Device (optional – shown)
13 System Battery
14 Primary (CPU1) Riser PCIe 5.0
  • 1x 16 FH and 1x16 LP slots
15 OCP Slot port
16 Front Display Port and USB 2.0 connector (optional feature)
17 LP SlimSAS ports (1 & 2)
18 Chipset
19 Front I/O and USB 3.2 Gen1 connector
20 SATA Optical port
21 Socket 1 MCIO connector
22 CPU 1 and CPU 2 (shown with High Perfromance Heatsink)
23 Hot plug (dual rotor) High Performance Fan Kit (7 fans)
  • Option: Closed-loop Liquid Cooling Heat Sink Fan FIO Bundle Kit
24 HPE Hybrid Capacitor or HPE Storage Battery holder

Rear View
Rear View - Standard for all DL360 Gen11

1 Slot 1 PCIe 5.0 – Full Height
2 Slot 2 PCIe 5.0 – Low Profile*

Notes: *Shown with optional NS204i-u Boot Device

3 Option: Slot 3 PCIe 5.0 (Requires 2nd processor)
  • Low Profile and Full Height options
4 Redundant Power Supply (1 & 2 as shown)
5 Video (VGA) port
6 OCP 3.0 Slot 2: x16 PCIe 5.01,2 (Requires 2nd Processor)
7 Serial port (optional - shown)
8 iLO Management Port
9 USB 3.2 Gen1 Ports
10 OCP 3.0 Slot 1: x16 PCIe 5.01

Notes:

  1. Supports various NICs, up to 200GbE.
  2. Or supports each slot with x8 PCIe 5.0 under one processor, with the selection of "P51911-B21, CPU1 to the "OCP2 x8 Enablement Kit".

HPE ServicesServices:

HPE POINTNEXT SERVICES

HPE Pointnext Services brings together technology and expertise to help you drive your business forward and prepare for whatever is next.

Operational Services from HPE Pointnext Services

HPE Pointnext Tech Care provides fast access to product-specific experts, an AI-driven digital experience, and general technical guidance to help enable constant innovation. We have reimagined IT support from the ground up to deliver faster answers and greater value. By continuously searching for better ways to do things—as opposed to just fixing things that break—HPE Pointnext Tech Care helps you focus on achieving your business goals.

HPE Pointnext Complete Care is a modular, edge-to-cloud IT environment service that provides a holistic approach to optimizing your entire IT environment, and achieving agreed upon IT outcomes and business goals through a personalized and customer-centric experience. All delivered by an assigned team of HPE Pointnext Services experts.

HPE Integration and Performance Services help you customize your experience at any stage of your product lifecycle with a menu of services based on individual needs, workloads, and technologies.

  • Advise, design, and transform
  • Deploy
  • Integrate and migrate
  • Operate and improve
  • Financial Services
  • Greenlake Management Services
  • Retire and sanitize
  • IT Training and personal development

Other related services

HPE Education Services delivers a comprehensive range of services to support your people as they expand their skills required for a digital transformation. Consult your HPE Sales Representative or Authorized Channel Partner of choice for any additional questions and support options.

Defective Media Retention is optional and allows you to retain Disk or eligible SSD/Flash Drives replaced by HPE due to malfunction.

HPE GREENLAKE

HPE Greenlake is HPE’s market-leading IT as-a-Service offering that brings the cloud experience to apps and data everywhere – data centers, multi-clouds, and edges – with one unified operating model. HPE GreenLake delivers public cloud services and infrastructure for workloads on premises, fully managed in a pay per use model.

Documentation:

Download the HPE ProLiant DL360 Gen11 server Datasheet (.PDF)

Download the HPE ProLiant DL360 Gen11 server Quick Specs (.PDF)
