Overview:
Discontinued
We encourage you to check out our HPE ProLiant Gen11 Servers.
Notice
This unit has been discontinued and is no longer available for purchase.
The HPE ProLiant DL180 Gen10 series is replaced by HPE ProLiant Gen11 Servers.
| End-of-Life (EOL) |
Q1 2025 |
We will no longer provide technical support or hardware replacement for this product after End-of-Life (EOL) date.
Is maximizing your business reach and goal a challenge you are
facing because your IT is not keeping pace with your data
growth?
The secure HPE ProLiant DL180 Gen10 server delivers on
scalability, performance, and reliability thus making it the ideal
platform for businesses ready to run on-premises and hybrid
cloud applications. These businesses need the right mix of
compute and storage, enabling them to achieve their most
important goals.
What's new
- Supports the second generation Intel® Xeon® Scalable processor family.
- Twelve LFF drive chassis supporting
SAS/SATA HDDs/SSDs with max 48 TB
storage.
- HPE InfoSight provides a cloud-based
analytics tool that predicts and prevents
problems before your business is impacted.
- HPE OneView offers an automated,
template-driven approach for deploying, provisioning, updating, and integrating
compute, storage, and networking
infrastructure.
- HPE Small Business Solutions are complete
solutions and workload optimized built on
ProLiant servers, providing the foundational
on-premise component for the Hybrid Cloud.
- Available aggressively priced SMB offer
models regionally released as ”Smart Buy
Express” in the U.S. and Canada, ”Top Value”
in Europe, and ”Intelligent Buy” in Asia
Pacific.
Features:
Dense Storage at Optimal Performance for Web Infrastructure and Service Providers
The flexible design provides choice of options and ability to scale. It is configured to meet the new standard of growing data center needs. The server supports Intel® Xeon® Scalable Processor series, up to eight cores (maximum 24) with 16 DDR4 2666 MHz (256 GB maximum).
Two PCIe 3.0 slots and HPE iLO 5, UEFI and legacy boot mode, along with the
standard HPE Dynamic Smart Array S100i. You have a choice of HPE Flexible
Smart Array or HPE Smart HBA controllers for performance or additional features.
500W multi-output, up to 94% efficiency (Titanium), Flexible Slot PS; Standard 3-3-
3 warranty; HPE Secure Encryption.
Comprehensive and Cost-effective Management
HPE ProLiant DL180 Gen10 server offers comprehensive firmware management
with HPE iLO5 that includes install sets created by Smart Update Manager (SUM).
It has the ability to create multiple rollback sets and ability to view and delete
scheduled jobs at no additional licensing cost.
Scalable and reliable model to run multi-workload for better business performance
and growing Data center needs. Cost optimization, reliability and expandability for
cloud and virtualization requirements. Setting security standards making it the most
secure Industry standard server portfolio.
Specifications:
| HPE ProLiant DL180 Gen10 Server Specifications |
| Processor Name |
Intel Xeon Scalable first and second generation processors |
| Processor family |
Intel® Xeon® Scalable 8200, 6200, 5200, 4200 4100, 3100 series |
| Processor core available |
Up to 24 core, depending on processor |
| Processor cache |
8.25-35.75 MB L3, depending on processor |
| Processor speed |
3.8 GHz, maximum depending on processor |
| Expansion slots |
3 Standard in Primary Riser |
| Maximum memory |
HPE DDR4 Smart Memory
Maximum capacity (RDIMM) 1 TB 16 x 64 GB RDIMM @ 2933 MT/s
Maximum capacity (LRDIMM) 1 TB 16 X 64 GB LRDIMM @ 2933 MT/s |
| Memory slots |
16 slots maximum |
| Memory type |
HPE DDR4 SmartMemory |
| Included hard drives |
None ship standard, 12 LFF drives and 8 SFF drives supported |
| Optical drive type |
SATA DVD-ROM Optical Drive / Optical Drive 5mm SATA DVD-RW / Mobile USB DVD-RW Optical Drive |
| System fan features |
4-6 Fans |
| Network controller |
Embedded 2-Port 1GbE |
| Storage controller |
Embedded 14-Port S100i |
| Minimum dimensions ( H x W x D) |
8.73 x 44.54 x 63.47 cm |
| Weight |
13.0 kg |
| Infrastructure management |
HPE iLO5, InfoSight and OneView |
| Warranty |
3/3/3 - Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at:
http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support |
| Drive supported |
8 SFF SAS/SATA HDD/SSD, 12 LFF SAS/SATA HDD, M.2 SATA options supported |
Services:
HPE Pointnext
HPE Pointnext leverages our breadth and depth of technical expertise and innovation to help to accelerate digital transformation. A comprehensive portfolio that includes—Advisory, Professional, and Operational Services is designed to help you evolve and grow today and into the future.
Operational Services
- HPE Flexible Capacity is a new consumption model to manage ondemand capacity, combining the agility and economics of public cloud with the security and performance of on-premises IT.
- HPE Datacenter Care offers a tailored operational support solution built on core deliverables. It includes hardware and software support, a team of experts to help personalize deliverables and share best practices, as well as optional building blocks to address specific IT and business needs.
- HPE Proactive Care is an integrated set of hardware and software support including an enhanced call experience with start to finish case management helping resolve incidents quickly and keeping IT reliable and stable.
- HPE Foundation Care helps when there is a hardware or software problem offering several response levels dependent on IT and business requirements.
Advisory Services includes design, strategy, road map, and other services to help enable the digital transformation journey, tuned to IT and business needs. Advisory Services helps customers on their journey to Hybrid IT, Big Data, and the Intelligent Edge.
Professional Services helps integrate the new solution with project management, installation and startup, relocation services, and more. We help mitigate risk to the business so there is no interruption when new technology is being integrated in the existing IT environment.
